Piezo Ultrasonic Atomizer

Piezo Ultrasonic Atomizer

Piezo Ultrasonic Atomizer

Product Details:

Place of Origin: CN
Brand Name: HM
Certification: CE, RoHS, SGS ISO9001:2008, ISO14001:2015
Model Number: ALL

Payment & Shipping Terms:

Minimum Order Quantity: 20
Price: $1~$500
Delivery Time: 30 WORK DAYS
Payment Terms: MoneyGram PAYPLE
Supply Ability: 10000PCS/MONTH
Contact Now
Detailed Product Description

Features

Compact size
High reliability
High energy conversion


Scope of applications

Beauty instrument



Dimensions

schematic diagram of piezo atomizer.png


Part Numbering

Part numbering_atomizer



Specification



Model Material of mesh Hole Size Atomizing Capacity Resonance Frequency Electrical capacitance Impedance Driving voltage OD /D1 Thickness/t
[ µm ] [ ml/min ] [ KHz ] [ nF ] [Ω] [Vp-p] [ mm ] [ mm ]
    ±10 ±30%   ±20% ±0.3 ±0.05
WHTF135-14.0C-1(4) Ni-Co 4 0.68 135±8 3.5 ＜100 55 14 0.6
WHTF135-14.0C-1(6) Ni-Co 6 1.87 135±8 3.5 ＜100 55 14 0.6
WHTF135-14.0C-1(8) Ni-Co 8 4.9 135±8 3.5 ＜100 55 14 0.6
WHTF113-16.0C-1(4) Ni-Co 4 0.89 113±8 4.9 ＜100 55 16 0.6
WHTF113-16.0C-1(6) Ni-Co 6 3.46 113±8 4.9 ＜100 55 16 0.6
WHTF113-16.0C-1(8) Ni-Co 8 6.87 113±8 4.9 ＜100 55 16 0.6
WHTF113-20.0C-1(4) Ni-Co 4 0.95 113±11 6.3 ＜100 55 20 0.6
WHTF113-20.0C-1(6) Ni-Co 6 3.21 113±11 6.3 ＜100 55 20 0.6
WHTF113-20.0C-1(8) Ni-Co 8 9.83 113±11 6.3 ＜100 55 20 0.6
WHTF135-14.0C-1(6) SUS304 6 0.35 135±8 3.5 ＜100 55 14 0.6
WHTF135-14.0C-1(8) SUS304 8 0.7 135±8 3.5 ＜100 55 14 0.6
WHTF135-14.0C-1(10) SUS304 10 1.15 135±8 3.5 ＜100 55 14 0.6
WHTF135-14.0C-1(12) SUS304 12 1.75 135±8 3.5 ＜100 55 14 0.6
WHTF113-16.0C-1(6) SUS304 6 0.47 113±8 4 ＜100 55 16 0.6
WHTF113-16.0C-1(8) SUS304 8 1.6 113±8 4 ＜100 55 16 0.6
WHTF113-16.0C-1(10) SUS304 10 2.6 113±8 4 ＜100 55 16 0.6
WHTF113-16.0C-1(12) SUS304 12 3.5 113±8 4 ＜100 55 16 0.6
WHTF113-20.0C-1(6) SUS304 6 0.96 113±11 6.5 ＜100 55 20 0.6
WHTF113-20.0C-1(8) SUS304 8 2.75 113±11 6.5 ＜100 55 20 0.6
WHTF113-20.0C-1(10) SUS304 10 4.3 113±11 6.5 ＜100 55 20 0.6
WHTF113-20.0C-1(12) SUS304 12 6.95 113±11 6.5 ＜100 55 20 0.6






* Customize on request.



Key Technical Index Unit Value
Relative dielectric constant εr3T - 3500±20%
Electromechanical coupling factor Kp - 70%
Longitudinal piezoelectric strain coefficient d33 10-12C/N ≥650
Piezoelectric voltage constant g33 10-3Vm/N 17
Elastic flexible coefficient S11E 10-12m2/N 14.3
Elastic flexible coefficient S33E 10-12m2/N 18.5
Dielectric loss tgδ 10-3 ≤1.5
M quality factor Qm - 45
Curie temperature TC ℃ 240
Density ρ g/cm3 7.9
