    Product Details:

    Place of Origin: wuxi
    Brand Name: HM
    Model Number: KHZ-Mhz

    Payment & Shipping Terms:

    Minimum Order Quantity: 100
    Price: 1000.0 RMB
    Packaging Details: REEL
    Delivery Time: 25 day
    Payment Terms: MoneyGram
    Supply Ability: 10000pcs per month
    Contact Now
    Detailed Product Description
    Material: Crystal Frequency: Khz-Mhz
    Insertion Loss: <6dB

    1.   (Model ): LST38.4M6C
    2.   (Nominal Center Frequency): 38.4MHz
    3.   (Pass Band Width at 3dB): ≥±3kHz
    4.   (Ripple in Pass Band Width): ≤2.0dB
    5.   (Insertion Loss): ≤5.5dB
    6.   (Stop Band Width ): ≤±10kHz @40dB
          ≤±12.5kHz @60dB
    7.   (Guaranteed Attenuation): ≥60dB
    8.   (Terminating Impedance): 50Ω
    9.   (Input level): 0～15dBm
    10.   (Operating Temperature Range): -20℃～+70℃
    11.   (Dimensions): 25mm×15mm×10mm

    crystal filter Constant temperature crystal Warm crystal oscillator
