LTWC455A/LTWC455B/LTWC455C/LTWC455D/LTWC455E/LTWC455F/LTWC455G/LTWC455H/LTWC455I

LTWC455A/LTWC455B/LTWC455C/LTWC455D/LTWC455E/LTWC455F/LTWC455G/LTWC455H/LTWC455I

LTWC455A/LTWC455B/LTWC455C/LTWC455D/LTWC455E/LTWC455F/LTWC455G/LTWC455H/LTWC455I

Product Details:

Place of Origin:	CHINA
Brand Name:	HM
Model Number:	KHZ

Payment & Shipping Terms:

Minimum Order Quantity:	1000
Price:	6.5 RMB
Packaging Details:	REEL
Delivery Time:	25 day
Payment Terms:	MoneyGram, Western Union, T/T
Supply Ability:	500000PIECE/MONTH

Contact Now

Detailed Product Description

center frequency :455khz

6dB bandwidth :4-30khz

50dB bandwidth :7.5-60khz

ripple :2dB

insersion loss :2dB

stop band attenuation: 50dB

Contact Details

hanse-john electronic Co.,Ltd.

Contact Person: Mr. liuhongmao

Tel: 86-0510-13912395130

Fax: 86-510-88213035
